    CCVP/CCIP QoS(642-642) Lab – DSCP & CoS

    By admin | May 14, 2009

    You are required to configure the fa0/1, fa0/10 and fa0/11 ports on the Cisco Catalyst 2950 switch according to the following:
    On port fa0/1, trust all incoming DSCP settings.
    On port fa0/11, trust all incoming CoS settings.
    On port fa0/10, trust the incoming CoS setting only if a Cisco IP Phone is connected to the fa0/10 port: otherwise do not trust any CoS or DSCP markings coming in.

    1

    The Answer:

    2950-SWITCH>en
    2950-SWITCH#config terminal
    2950-SWITCH(config)#cdp enable
    2950-SWITCH(config)#interface fastethernet0/1
    2950-SWITCH(config-if)#mls qos trust dscp
    2950-SWITCH(config-if)#no sh
    2950-SWITCH(config-if)#interface fastethernet0/11
    2950-SWITCH(config-if)#mls qos trust cos
    2950-SWITCH(config-if)#no sh
    2950-SWITCH(config-if)#interface fastethernet0/10
    2950-SWITCH(config-if)#mls qos trust device cisco-phone
    2950-SWITCH(config-if)#no sh
    2950-SWITCH(config-if)#end
    2950-SWITCH#show mls qos interface fastethernet0/1
    2950-SWITCH#show mls qos interface fastethernet0/11
    2950-SWITCH#show mls qos interface fastethernet0/10
    2950-SWITCH#copy running-config startup-config

    If you want to learn more, you can visit:

    http://www.cisco.com/en/US/docs/switches/lan/catalyst2940/software/release/12.1_22_ea2/configuration/guide/swqos.html

    That is all, hope to helpful for you. Best Luck for ur QoS 642-642 Exam.

    If you need the complete pass4sure test questions for 642-642 Exam, you can visit Latest Pass4sure 642-642,maye it helpful for ur exam!
